Характеристики
| Параметр |
Значение |
| Производитель: |
QJZ |
| MPN: |
5306-2RS |
| Bearings Type: |
Angular Contact Ball Bearing |
| Bore Diameter: |
30 mm |
| Outside Diameter: |
72 mm |
| Ширина: |
30.2 mm |
| Материал: |
Steel |
| Модель: |
5306-2RS |
| Гарантия: |
30-Days FREE RETURN;1-Year Buyer-Protection Warranty |
| Shipping Service: |
[FREE SHIPPING By Standard Priority/Ground Mail Service] |
| Shipment Awareness: |
[Shipment Only Proceed On Regular Business Days] |
| Office Hours: |
[M-F ; 8:00AM PST-5:00PM PST] |
| Shipping & Handling: |
[Order By [1:00 PM PST] For SAME-DAY Priority Shipping] |
| [OD]Outer Diameter(MM): |
72 MM |
| [W]Width(MM): |
30.2 MM |
| [ID]Bore Diameter(MM): |
30 MM |
| Closure Type: |
Two Contact Seals |
| Material:: |
Chrome Steel SAE-52100 |
| Lubrications: |
Chevron SRI-2 Grease |
| Dynamic Load Rating (Cr): |
41600 N |
| Static Load Rating (Cor): |
29000 N |
| Max. Shaft Shoulder Dia. Inner (Ui): |
37.0 MM |
| Row Type & Fill Slot: |
Double-Row Non-Fill Slot |
| Radius (min) (rs): |
1.10 MM |
| Min. Housing Shoulder Dia., Outer (Uo): |
66.00 MM |
| Standard Clearance: |
C0 |
| Precision Class: |
ABEC 1 | ISO P0 |
| Alternative Numbers 1: |
5306A.2RSJ1,5306PP,5306SBKSS,5306LLU,5306DDU,5306VV |
| Alternative Numbers 2: |
5306LLB,5306-2NSE,B5306-2RSR,3206A.2RS1,5306-2NSL,5306RS |
| Alternative Numbers 3: |
Consolidated Bearing 5306-2RS;NTN 5306ALLUA1X2CS30/LX16Q3 |
| Alternative Numbers 4: |
Koyo 53062RS;SKF 3306 A-2RS1/VT113F2;NSK 3306B-2RSTNC3 |
| Alternative Numbers 5: |
NTN 5306ALLUA1X2CS30V4;Nachi 5306-2NS;FagBearing 3306-BD-XL-2HRS |
| Alternative Numbers 6: |
Bearing Limited 5306-2RS/C3;Koyo 53062RSCD3;3306 A-2RS1TN9/W64 |
| Common Applications 1: |
agricultural machinery;conveying equipment;electric motors; |
| Common Applications 2: |
CNC machinery;trucks;mining equipment;train;robotics |
| Common Applications 3: |
dental equipment;elevators;rolling mills;ship rudder shafts |
| Common Applications 4: |
electric motors, automotive starters and alternators, |
| Common Applications 5: |
compressors, conveyors;Go Kart wheels, skateboards |
| Common Applications 6: |
outdoor power equipment;industrial applications. |
| Common Applications 7: |
Sprint Rear Axle Bearing, Offroad Wheel Bearing, clutches, drives |
| Country of Origin: |
China |
| [W: |
30.2 MM |
| [OD: |
72 MM |
| [ID: |
30 MM |
| Универсальный товарный код: |
00722815270392 |
